The break is engaged by the rider pushing forward and applying pressure with the palm of their hand until the lever snaps into position.Ģ. Push-to-lock wheel locks are the most common. There are various types of wheel locks available:ġ. Using wheel locks as a braking device can cause injury and excessive tire wear and should never be used in this manner. The manufacture, while building your chair on the factory floor, will appropriately choose between the curved and standard axle plates in order to accommodate your preferred seat-to-floor height. In most cases, the customer will just specify their required seat-to-floor height. This allows the chair to be configured to more seat-to-floor heights. Curved Axle: Unlike the rectangle axle plate, the curved axle plate is curved.
Note that with this option the overall length of the chair is extended. This changed center of gravity corrects any imbalance resulting from the amputee’s lack of forward body weight.
The Mono backrest system offers an optional dynamic function, 35° angle adjustment, and folds forward for easy transport.
By mounting the backrest to a single central post, the backrest and chair widths may be selected independently, hardware interference is eliminated to allow for infinite adjustment of lateral thoracic supports, and the backrest can achieve 2” of midline backrest offset. The Mono backrest system’s single-post offers limitless seating and positioning capabilities. Audible clicks index its position as it is elevated.
The elevating/articulating legrest includes 2″ of height adjustment to better align with the knee joint for a natural motion. A tapered locking mechanism prevents the hanger from loosening over time. The new swing-in/swing-out hanger design features an intuitive bi-directional release lever that follows your hand’s movement.
#Quickie wheelchair manual manual#
The IRIS manual wheelchair features 40° or 55° rotation ranges that can be set to achieve up to 45° or 60° of posterior rotation for superior positioning. This results in a smooth tilting motion that is easy for you to control and allows for the shortest possible wheelbase that is easy for you to maneuver. Intelligent rotation in space technology means the seat frame rotates around the user’s center of gravity. Quickie IRIS tilt-in-space manual wheelchair features up to 55° of intelligent rotation in space technology, the broadest range of positioning and caregiver options, numerous adjustments, and it’s one of the lightest tilt-in-space wheelchairs available today.Ĥ0° or 55° of intelligent rotation in space technology
